900&2100 Dual band PICO Repeater 200mW for signal coverage
ZD-DR-900/2100-20dBm
This 900 & 2100 dual‑band PICO repeater is a 200mW signal booster built for cellular signal coverage. It supports downlink 925‑960MHz, 2110‑2170MHz and uplink 880‑915MHz, 1920‑1980MHz. Max downlink output power reaches 23±2dBm, uplink 20±2dBm, with maximum gain 70±3dB and adjustable gain step 1dB. Equipped with ALC function, VSWR ≤2.0 and complies with 3GPP standards. It adopts MS‑4.3‑10‑Female RF connector, powered by AC 100‑240V adaptor, power consumption ≤35W. Dimension 268*220*50mm, weight ≤4.5kg, IP40 rating, operating temperature‑25℃~+55℃. Local LED status indicator and long MTBF ≥50000 hours. Compact pico repeater ideal for indoor small‑area signal enhancement, offices, retail stores and indoor cellular coverage solutions.
Delivery
EXW,FOB,CIF
minimum order
1 piece
Country of Origin
CHINA
Quantity:
This compact dual band pico repeater, high‑performance 900 2100mhz pico repeater, is a 200mW signal repeater designed as cellular pico repeater for indoor cellular signal enhancement. It covers downlink 925‑960MHz, 2110‑2170MHz and uplink 880‑915MHz,1920‑1980MHz. Max downlink output power 23±2dBm, uplink 20±2dBm, maximum gain 70±3dB with 1dB gain adjustment step. Built‑in ALC protection, VSWR ≤2.0, fully compliant with 3GPP TS36.106 and TS36.143 standards. This dual band pico repeater uses MS‑4.3‑10‑Female RF connector, powered by AC 100‑240V adapter with power consumption ≤35W. Dimension is 26822050mm, weight ≤4.5kg, IP40 enclosure, operating temperature‑25℃~+55℃, LED status indicator and MTBF ≥50000 hours. Reliable 900 2100mhz pico repeater, the 200mW signal repeaterandcellular pico repeater, delivers stable signal amplification for offices, shops and other small‑area indoor coverage scenarios.
- Power Supply and Mechanical Specifications
| Power Supply | AC 100~240V, 50/60Hz Adaptor | |
| Dimension and Weight | 268*220*50mm,≤4.5kg | |
| Power Consumption | ≤35W | |
| Temperature | -25~+55℃ | |
| Humidity | ≤95% | |
| Environmental Class | IP40 | |
| RF Connector | MS_4.3-10-Female, 50ohm | |
| MTBF | ≥50000 hours | |
| Monitor Interface | Local Monitor: Manually control, operating status: LED | |
| Product number | 900&2100Dual band Pico selective repeater,200mW | |
- Electronic Specifications
| Item | Specification | ||
| Downlink | Uplink | ||
| Frequency Range | 900 | 925 - 960MHz | 880 -915MHz |
| 2100 | 2110 - 2170MHz | 1920- 1980MHz | |
| bandwith | Customized by customer | ||
| Output Power (Max.) | 23±2dBm | 20±2dBm | |
| Gain(Max.) | 70±3dB | 70±3dB | |
| Gain Adjustable Range/Step | ≥25dB/1dB | ||
| Gain Adjustable Error | Gain adjustable range is 0~20dB, error≤1dB; ≥21dB, error≤1.5dB | ||
| ALC | When adding ≤10dB at max. Output level, output variation ≤±2dB, When adding >10dB, output variation ≤±2dB or be off. | ||
| NF | ≤6dB at max. gain | ||
| Time Delay | ≤5.0μs | ||
| VSWR | ≤2.0 | ||
| Ripple in band | ≤4dB | ||
| Restraint out of the band | 2.5MHz≤ f_offset＜5 MHz ≥40dB | ||
| 5 MHz ≤f_offset ≥60dB | |||
| Spurious Emission | Complies with 3GPP TS36.106 and 3GPP TS36.143 | ||
| Spectrum Emission Mask | Complies with 3GPP TS36.106 and 3GPP TS36.143 | ||
| ACRR | Complies with 3GPP TS36.106 and 3GPP TS36.143 | ||
| Frequency Stability | ≤0.05ppm | ||
| EVM | ≤8% | ||
